JVC Video Switchers

<< Back to Video Switches

JVC has a few consumer grade switchers available.  Below are information from their website:

JX-S111/JX-S111S

JX-S111

JX-S111S

• Video Signal Format: NTSC
• AV inputs: 4 lines (incl. 2 S-Video jacks)
• AV outputs: 2 lines (incl. 1 S-Video jack)
• 3 Component Inputs Line 1 - 3
• Monitor output: 1 line (incl. 1 S- Video jack)

The JX-S111 is an affordable A/V Switcher with 5 A/V Inputs (2 w/ S-Video) and 2 A/V 0utputs (1 w/ S-Video). A Monitor output with S-Video is also provided. The passive design means that it can be operated even when no power supply is available, making it ideal for portable application.

JX-S555

The JX-S555 is a video switcher with component video and digital audio connections.   This professional quality switcher uses the highest quality circuitry for no signal loss at any point.  It features 5 A/V Inputs, 5 A/V Outputs, 2 Component Video Inputs with Digital Audio, 1 Component Video Output connections

• AV Input: 5 lines ( S-Video, Video, Audio L/R)
• AV Output: 4 lines (S-Video, Video, Audio L/R)
• Component input: 2 lines
• Monitor output: 2 lines
• Optical inputs: 2
• Optical output: 1
• Video Frequency response: Composite 12 MHz, Component 30 MHz
• Video Reference input: Composite 1.0 Vp-p (75 ohms unbalanced), Component Y: Vp-p 1.0V (75 ohms), Cb/Pb & Cr/Pr: Vp-p 0.7V (75 ohms)
• Maximum video input level: Composite 1.0 Vp-p, Component Y: Vp-p 1.5V (75 ohms), Cb/Pb & Cr/Pr: Vp-p 1.0V
• Video Crosstalk: 50 dB or more (45 dB or more between Y/C in the same channel)
• Video S/N ratio: 50 dB or more
• Audio Reference input level: -10 dBV, 47k ohms
• Maximum Audio input level: +6 dBV (2.0 VRMS), 1kHz
• Audio S/N ratio: 80 dB or more
• Audio Output level: -10 dBV (with reference input, 1 kHz)
• Audio S/N ratio: 80 dB or more
• Audio Frequency Response: 5-50 kHz
• Audio Total Harmonic Distortion: 0.01 % (with reference input, 1kHz)
• Optical digital signal: [wavelength] 660 nm +/-30 nm, [output] -15 dBm - -2121dBm (at the end of reference level optical fiber output)
• Power Requirements: AC 120V, 60 Hz , Power consumption: 15 W (Power On), 1.2 W (Standby)
• Remote control unit (RM-AS700), SUM-3/AA/R6 battery x 2
• Video Signal Format: NTSC
• 1 year parts 90 day labor warranty
• Weight: 6.4 lbs
• Width: 17 3/16"
• Height: 4 1/8"

JX-S777

The JX-S777 is the first video switcher with full digital video, component video and digital audio connections. This professional quality switcher uses the highest quality circuitry for no signal loss at any point. It features 8 A/V Inputs, 5 A/V Outputs, 2 Component Video Inputs with Digital Audio, 1 Component Video Output with Digital Audio and 3 i-Link (fire wire)

• AV Input: 8 lines ( S-Video, Video, Audio L/R)
• AV Output: 5 lines (S-Video, Video, Audio L/R)
• Component input: 2 lines
• Monitor output: 2 lines
• DV input/outputs: 3
• Optical inputs: 2
• Optical output: 1
• Processor in/out: 1 line
• Video Frequency response: Composite 12 MHz, Component 30 MHz
• Video Reference input: Composite 1.0 Vp-p (75 ohms unbalanced), Component Y: Vp-p 1.0V (75 ohms), Cb/Pb & Cr/Pr: Vp-p 0.7V (75 ohms)
• Maximum video input level: Composite 1.0 Vp-p, Component Y: Vp-p 1.5V (75 ohms), Cb/Pb & Cr/Pr: Vp-p 1.0V
• Video Crosstalk: 50 dB or more (45 dB or more between Y/C in the same channel)
• Video S/N ratio: 50 dB or more
• Audio Reference input level: -10 dBV, 47k ohms
• Maximum Audio input level: +6 dBV (2.0 VRMS), 1kHz
• Audio S/N ratio: 80 dB or more
• Audio Output level: -10 dBV (with reference input, 1 kHz)
• Audio S/N ratio: 80 dB or more
• Audio Frequency Response: 5-50 kHz
• Audio Total Harmonic Distortion: 0.01 % (with reference input, 1kHz)
• Optical digital signal: [wavelength] 660 nm +/-30 nm, [output] -15 dBm - -2121dBm (at the end of reference level optical fiber output)
• Power: AC 120V, 60 Hz 15 W (Power On), 1.2 W (Standby)
• Remote control unit (RM-AS700), SUM-3/AA/R6 battery x 2
• Video Signal Format: NTSC
• 1 year parts 90 day labor warranty
• Weight: 8.4 lbs
• Width: 17 3/16"
• Height: 4 1/8"
